Installation Reports
TABLE OF CONTENTS
• Executive Summary
Introduction
The purpose of this work is to install the Vibration Isolation MB 3000 system for the Thermo
Fisher Scientific Talos F200X at the University of North Dakota Grand Forks. Thermo Fisher
Scientific hired VEC to install the field cancellation system and provide a report of the completed
work.
Summary Results
Below is a summary of the results:
- MB3000 ON PASSED the Vibration specifications
• Introduction
The purpose of this work is to install the Vibration Isolation MB 3000 system for the Thermo Fisher Scientific Talos F200X at the University of North Dakota Grand Forks.
Thermo Fisher Scientific hired VEC to install the field cancellation system and provide a report of the completed work.
• Product Details
| Part Delivered | Serial Number | Software |
|---|---|---|
| MB3000 | 221104R3 | Site-Specific Tune |
• Summary of Work
We installed the system by
- Positioning the Daeil under the microscope
We tested the system by
- Creating and uploading a site specific tune
- Collecting vibration data to verify the performance
We left the system
- In position and on
• Procedures
Vibration
VEC conducted vibration measurements in six directions. Acceleration measurements were taken at a bandwidth of 200 with units of um/s (RMS).
The acceleration spectra with 200 bandwidths were recorded.
• Setup
| Vibration | |
|---|---|
| Bandwidth | 200 |
| Lines | 1600 |
| Window | Hanning |
| Coupling | ICP 2mA |
| Average Type | Stable |
| Duration | 60 |
| Engineering Units | um/s (RMS) |
Vibration
VEC conducted vibration measurements in three directions. Acceleration measurements were
taken at a bandwidth of Hz with units of um/s. The acceleration spectra with Hz bandwidths were
recorded.
• Setup
| Part Delivered | |
|---|---|
| Bandwidth | Hz |
| Duration | seconds |
| Engineering Units | um/s |
• Specifications
VEC used the following specifications for the project.
Specification Summary
| PTool | Specification |
|---|---|
| Thermo Fisher Scientific Talos F200X |
Vibration VC-F X & Y 1.56 um/s 1Hz - 100Hz VC-E Z 3.12 um/s 1Hz - 100Hz |
Detailed Specifications
Figure 1: Thermo Fisher Scientific Talos F200X – 1 Vibration Specification
5.4.1 VC Curves for System Enclosure
| System | Vertical | Left to right | Front to back |
|---|---|---|---|
| Talos F200X,S; TEM info limit 0.12nm | E | F | F |
| Talos F200X,S; STEM res. 0.16nm | E | F | F |
| Talos F200C; TEM info limit 0.15nm | E | F | F |
| Talos F200C; STEM res. 0.20nm | E | F | F |
| VC-E |
• Floor a 700 kg/m2, indication > 29 cm thick • Rigid support structure with small spans or heavy foundation plate • Zone VC-E separately funded, keep around by dilation free of residual building • Technical rooms, elevators, stairways and circulation areas outside dilated zone VC-E • At the location of the dilatation disconnect channels and pipes to prevent transmission of vibration. No vibration sources in zone VC-E • Technical rooms on distance. isolate vibration sources outside zone VC-E • Zone VC-E on ground floor or 1st floor |
| VC-F |
• Floor a 1 000 kg/m', indication > 58 cm thick, heavy foundation plate • Zone VC-F separately funded, keep around by dilation free of residual building • Technical rooms, elevators, stairways and circulation areas outside dilated zone VC-F • At the location of the dilatation disconnect channels and pipes to prevent transmission of vibration • No vibration sources in zone VC-F • Technical rooms on distance, isolate vibration sources outside zone VC-F • Zone VC-F on ground floor |
• Results
Summary Results
Below is a summary of the results:
- MB3000 PASSED the Vibration specifications
Detailed Results
| Type | Position | Direction | Specification | Measurement | Result |
|---|---|---|---|---|---|
| Vibration | Floor | X-Axis (VC-F) | 1.56 um/s 1Hz - 100Hz | 1 um/s @ 63 Hz | PASS |
| Y-Axis (VC-F) | 0.515 um/s @ 63 Hz | PASS | |||
| Z-Axis (VC-E) | 3.12 um/s 1Hz - 100Hz | 3 um/s @ 63 Hz | PASS | ||
| Isolators | X-Axis (VC-F) | 1.56 um/s 1Hz - 100Hz | 0.08 um/s @ 63 Hz | PASS | |
| Y-Axis (VC-F) | 0.107 um/s @ 3 Hz | PASS | |||
| Z-Axis (VC-E) | 3.12 um/s 1Hz - 100Hz | 0.133 um/s @ 32 Hz | PASS |
• Data
Thermo Fisher Scientific Talos F200X
Vibration
Figure 2: Ground X-Axis
Figure 3: Ground Y-Axis
Figure 4: Ground Z-Axis
Figure 5: Isolators X Axis
Figure 6: Isolators Y Axis
Figure 7: Isolators Z Axis
Figure 8: Transmissibility X Axis
Figure 9: Transmissibility Y Axis
Figure 10: Transmissibility Z Axis
